103409

Zinc Alloy Cam Lock

Details

The 103409 zinc alloy cam lock (known as a gas marking machine lock, medical cart lock, or parking meter lock) is designed to secure a wide range of equipment, including but not limited to metal and non-metal wooden doors, cabinets, boxes, tooling boxes, drawers, marking machines, medical carts, parking meters, and POS machines.

Features

  • Φ19.
  • Superior wafer lock barrel with flat keys.
  • Housing & barrel with zinc alloy.
  • Outer housing size as ABA existing products #3403 M size.
  • Over 800 key combinations.
  • Interchangeable Core.
  • Master key system is available.

The Industry Standard for Durable Zinc Alloy Security

Imagine a high-traffic Commercial Office or a modern Educational Institution where hundreds of Steel Lockers, Office Pedestals, and Storage Cabinets must be secured daily. In such environments, a lock must provide both high-frequency reliability and robust protection. The ABA 103409 Zinc Alloy Cam Lock is specifically engineered to meet these versatile demands. As a leading Lock Manufacturer, we have crafted this Cam Lock from premium-grade Zinc Alloy, ensuring exceptional Mechanical Reliability and a long lifecycle under heavy use.

The 103409 Model features a high-precision Disc Tumbler Mechanism that delivers a smooth operating experience while maximizing Asset Protection. It is an essential Security Component for Mailboxes, Display Cases, and Electronic Chassis. For our OEM/ODM partners, ABA provides customizable Keying Options and multiple Cam Configurations, including a sophisticated Master Key System for efficient facility management. Rely on ABA’s Precision Engineering to provide a cost-effective yet High-Security Locking solution that seamlessly integrates into your industrial or commercial hardware.

Related Video

RELATED PRODUCT

Top Security Cam Lock

Top Security Cam Lock



1. Top security dual systems PAGODA+DIMPLE
2. Housing & Barrel with Brass Alloy
3. Over 3,000 key combinations based on key in both positions
Over 90,000 key combinations based on key in one position
4. Almost the same spec. as Pagoda Cam Lock 101481, except the lock head is a little bigger
5. The end barrel with nut fitting (Cam is affixed by nut), Cam (various specs is available)
6. Our atm machine locks,gun cabinet locks,cabinet locks are designed to secure a wide range of applications, including but not limited to locker and security boxes, atm machine, metal and wooden cabinet, storage, gun cabinet, drawer, furniture, any cabinet and box.
High Security Quarter Turn Lock

High Security Quarter Turn Lock



1. Top security dual systems PAGODA+DIMPLE
2. Housing & Barrel with Brass Alloy
3. Over 3,000 key combinations based on key in both positions
Over 90,000 key combinations based on key in one position
4. Almost the same spec. as Pagoda Cam Lock 101481, except the lock head is a little bigger
5. The end barrel with nut fitting (Cam is affixed by nut), Cam (various specs is available)
6. Our atm machine locks,gun cabinet locks,cabinet locks are designed to secure a wide range of applications, including but not limited to locker and security boxes, atm machine, metal and wooden cabinet, storage, gun cabinet, drawer, furniture, any cabinet and box.
102446 charging pile lock

Charging Pile Lock

Details

The 102446 charging pile lock (known as locker lock, amusement machine lock, and vending machine lock) is designed to secure a wide range of equipment, including but not limited to metal and wooden cabinets, storage, drawers, furniture, museum display cabinets, machines and equipment, gun cabinets, and control cabinets.

Features

  • Φ19.
  • Zinc alloy housing & barrel.
  • Over 3,000 key combinations.
  • Accessory: Nut & Cam (Various specs cams depend on customization or refer to accessories).
  • Each lock has 1pc regular key and 1pc control key.
  • The control key has idling only, and the regular key for locking/unlocking.
  • The regular key is unworkable when the control key is inserted into the lock and turned to the 5:00 position (135 degrees).
  • The control key returns the lock position to 12:00, then the regular key resumes the opening function.
Mailbox Lock

Mailbox Lock


1. Superior wafer lock barrel
2. Housing & barrel with zinc alloy
3. Our drawer locks, wooden door locks, furniture locks are designed to secure a wide range of applications, including but not limited to metal and non metal, wooden door, cabinets, mailboxes, tooling box, drawers, furnitures, healthcare cabinets.
4. Over 500 Key combinations or key alike
5. Accessory: nut & cam (cam "A" per customer request, as for reference)
Disc Detainer Cam Lock Abloy Lock

Disc Detainer Cam Lock Abloy Lock


1. High Quality Key System
2. End Barrel with Nut
3. Housing & Barrel made of Brass or Zinc Alloy
4. Over 500 key combinations or key alike
5. Our vault locks, safe locks, locker locks are designed to secure a wide range of applications, including but not limited to metal and wooden cabinet, vault, safe, locker, doors, vending machine, gambling machine, furniture, amusement machine, tooling boxes.
Box, Security Boxes, Machine and Equipment
6. Accessory: Nut & Cam (Cam “A” upon customer request)
ARV-C004 waterproof cam lock

Water Proof Cam Lock (IP65)

Details

The ARV-C004 waterproof cam lock (also known as a cabinet lock, furniture lock, or vending machine lock) is designed for a wide range of equipment. They are used for securing terminal equipment, electronic, metal, wooden cabinets, pay phones, underground strobes, ATMs, enclosures, standers, kiosks, vending/game machines, safety boxes, lockers, letter boxes, postal boxes, coffers, AD showcases, coin-ops, vehicles, mail boxes & tool boxes, furniture, and more.

Features

  • Φ19.
  • IP65 Water Proof.

Materials

  • Zinc Alloy.

We are an IP65 Cam Lock Manufacturer: Cam Locks with Dust Shutters, for Locker, Ad Showcase, Coin-op, Vehicle, Mail & Tools Box, Furniture, etc.
