2341 Key Switch Lock
Zinc alloy housing & barrel
Contact silver plated , brass terminal
Our security system locks, computer housing locks, and ticket vendor locks are designed to secure a wide range of applications, including but not limited to security system, alarm system, computer housing, telephone, ticket vendor, etc.
100 combinations
Current Rating: 4A 125VAC, 2A 250VAC
Contact Resistance: 10 Milli-Ohms Max.
Insulation Resistance: 500 Meg-Ohms Min
Dielectric Strength: 1500VAC 1 minute
Reliable Industrial Key Switch for Secure Power Management
Imagine a Warehouse Manager or a Facility Engineer in a High-Traffic Commercial Building needing to restrict access to the control panel of a Cargo Lift or an Automated Gate System. Unauthorized usage can lead to safety incidents or operational errors. The ABA 103302 (2341) Key Switch Lock is the ideal Locking Solution designed to provide a physical layer of security for electronic controls. As a specialized Lock Manufacturer, we have crafted this Electric Key Switch with a robust Zinc Alloy body and durable Brass Contacts, ensuring long-term Mechanical Reliability for daily operation.
The 103302 Model is a vital Security Component for Access Control Systems, Elevator Panels, and Alarm Control Units. It enables precise Power Management and Circuit Control, allowing only authorized key holders to activate or deactivate essential machinery. For our OEM/ODM partners, ABA provides customizable Keying Options and multiple Cam Configurations to ensure a perfect fit for diverse cabinet requirements. Trust ABA’s Precision Engineering to deliver high-quality Hardware Components that combine electrical safety with dependable Asset Protection.
Related Video
RELATED PRODUCT
Flat Key Switch Lock
Details
The 103305 flat key switch lock (known as a garage door lock, electronic instrument lock, and computer server lock) is designed to secure a wide range of equipment, including but not limited to garage doors, alarm systems, computer servers, electronic instruments, vending machines, control boxes, electronic boxes, etc.
Specifications
- Current Rating: 4A /125VAC, 2A/250VAC.
- Contact Resistance: 10 Mill-Ohms Max.
- Insulation Resistance: 500 Meg-Ohm Min (500VDC).
- Dielectric Strength: 1500 VAC-1 Minute.
Features
- Superior wafer lock barrel with flat keys.
- Zinc alloy housing & barrel.
- Gold-plated contacts & terminals.
- Over 60 key combinations or all keys alike.
- The distance between two terminals is the biggest in the market.
- Terminals quantity upon customer's requests (max. 8 terminals).
- Key rotation degree, Key inserts way, and spring return function are optional for customers.
Accessory: housing nut (optional for customers).
