Key Switch
Top security PAGODA system
Zinc alloy housing and cylinder
Silver plated contacts and terminals
Our garage doors locks, electronic instrument locks, and computer server locks are designed to secure a wide range of applications, including but not limited to garage doors, alarm, computer server, electronic instrument, vending machine, control boxes, electronic boxes, etc.
Over 10000 combinations
SPECIFICATIONS:
Current Rating: 4A /125VAC, 2A/250VAC
Contact Resistance: 10 Mill-Ohms Max
Insulation Resistance: 500 Meg-Ohm Min (500VDC)
Dielectric Strength: 1500 VAC-1 Minute
Precision-Engineered Key Switch for Secure Power Control
Imagine an Industrial Control Panel or a High-Security Elevator System where unauthorized operation could lead to safety risks or operational downtime. Relying on simple push-buttons is not enough; you need a layer of physical authorization. The ABA 101380 Key Switch is the professional Locking Solution designed for such critical applications. As an industry-leading Lock Manufacturer, we have developed this Electric Key Switch with a durable Zinc Alloy housing and high-conductivity Brass Contacts, ensuring long-lasting Mechanical Reliability.
The 101380 Model is a vital Security Component for Access Control Systems, Security Alarms, and Medical Equipment. It allows for precise Power Management, ensuring that only authorized personnel can activate sensitive machinery. For our OEM/ODM partners, ABA offers various Keying Options, including Key Retaining or non-retaining functions, and diverse Circuit Configurations (SPST/SPDT). Trust ABA’s Precision Engineering to provide a reliable Key-Operated Switch that balances electrical safety with robust hardware Durability.
Related Video
RELATED PRODUCT
Key Switch Lock
Top security PAGODA system
Zinc alloy housing and cylinder
Silver plated contacts and terminals
Our vending machine locks, alarm system locks, and computer server locks are designed to secure a wide range of applications, including but not limited to garage doors, alarm system, computer server, electronic instrument, vending machine, control boxes, electronic boxes, etc.
Over 10000 combinations
SPECIFICATIONS:
Current Rating: 4A /125VAC, 2A/250VAC
Contact Resistance: 10 Mill-Ohms Max
Insulation Resistance: 500 Meg-Ohm Min (500VDC)
Dielectric Strength: 1500 VAC-1 Minute
ATM Machine Switch Lock
Details
The 101382 ATM machine switch lock (known as a garage door lock, electronic instrument lock, or computer server lock) is designed to secure a wide range of equipment, including but not limited to garage doors, alarm systems, computer servers, electronic instruments, vending machines, control boxes, electronic boxes, etc.
Specifications
- Current Rating: 4A /125VAC, 2A/250VAC.
- Contact Resistance: 10 Mill-Ohms Max.
- Insulation Resistance: 500 Meg-Ohm Min (500VDC).
- Dielectric Strength: 1500 VAC-1 Minute.
Features
- Top security PAGODA cylinder key switch lock system.
- Zinc alloy housing and cylinder.
- Silver-plated contacts and terminals.
- Over 10000 combinations.
Vending Machine Switch Lock
Details
The 101384 vending machine switch lock (known as an alarm system lock, and computer server lock) is designed to secure a wide range of equipment, including but not limited to garage doors, alarm systems, computer servers, electronic instruments, vending machines, control boxes, electronic boxes, etc.
Specifications
- Current Rating: 4A /125VAC, 2A/250VAC.
- Contact Resistance: 10 Mill-Ohms Max.
- Insulation Resistance: 500 Meg-Ohm Min (500VDC).
- Dielectric Strength: 1500 VAC-1 Minute.
Features
- Top security PAGODA system.
- Zinc alloy housing and cylinder.
- Silver-plated contacts and terminals.
- Over 10000 combinations.
